Terminal clamps / Folded Terminals / Metal components for MCB

Click here to send inquiry

Description

At PML, we have added new high speed presses, for manufacturing box or cage terminals or Terminal Connectors, high volume metal links, etc. The range of Terminal Connectors include cage/box terminals for Electric MCB’s, Energy Meters, Hose Clamps, etc. Depending on the size & shape of these parts, the multi slide automate can produce @ 50 - 60 pcs/min. Furthermore, we are offering Switch terminal connectors in varied size, shapes, material composition, standards, grades, finishing, coating and more based on custom specification. These machines can produce High precision & close tolerance Metal components up to 2 mm thickness & with production speed of 40-60 pcs per minute

Solutions

Electric Parts

Electric Parts

Automobile Parts

Automobile Parts

MCB Parts

MCB Parts

Electronic Parts

Electronic  Parts

Parts For Construction & Industries

Parts For Construction & Industries

Product Range

Spec Description Details
Material Strip form(Max mm) Width:50 mm
Thickness:2mm
Wire form(Max mm) Diameter 6 mm
Press Capacity(Ton) 20-25

Key Features of Parts

  • Withstand high temperature
  • Durable and Reliable
  • High Electrical Conductivity
  • Easy and Safe to install
  • Flexibility in wiring
  • Efficient performance
  • Shock Resistance
  • Corrosion Resistance
  • Abrasion Resistance
  • Customization Available

Material:

The range of Terminal Connectors are manufactured from premium quality raw material including brass, copper, stainless steel, steel or any material composition widely used in industries.

Sizes:

Any size available as per customer drawings and specifications or samples.

Thread:

ISO metric,UNC, UNF, BSP, BSPT, NPT, DIN, JIS, Standard or any type of international standard according to requirements.

Finish & Plating:

Natural, Nickel-Plated, Tinned or any type of plating and coating according to customer specifications.

Advantage over conventional press forming

  1. Saving material: Conventional press machine needs wider strips for automatic production; This machine uses exact width strip for production.
  2. High efficiency:Capability of automatic machine is efficient as compared to Conventional press saving energy consumption.
  3. More stable processing quality due to continuous automatic process
  4. Cheaper Tooling:One combined tool can replace several tools on several pressing machines.
  5. Automatic lubricating, less wear & Tear, suitable for mass production.

Features of Machines

Terminal clamping machine
  1. Machining of Precise parts:Available for economic mass production of parts for electronics,home appliances & Automobiles, & other precise components.
  2. High value-Added machining:One integrated process designed for bending,tapping,welding & assemblies works.
  3. Easy to produce many items in small lots:It is possible to produce many items in small lots by using only a pair of mold with basic tool.
  4. Operation system designed for ten sets per operator:Full automatic operation can be done by just feeding materials while being automatically stopped by a sensor when any error occurs on molds or materials
